Physical property:
Density: 122lbs / ft3
Density: 1.96g / cm3
Specific gravity:1.96
Thermodynamic properties:
Coefficient of thermal conductivity:0.23BTU/ft/hr/°F(0.35W/m °C)
Coefficient of linear expansion: 8.8x10-6in/in/°F(22.6x10-6mm/mm°C)
Flow coefficient:
Hacen Williams coefficient:C=150
Absolute roughness: 0.00021” (0.0053mm)
Elasticity coefficient:
Hoop elastic modulus:3.2x106psi (22.8Gpa)
Axial elastic modulus:1.82x106psi (12.6Gpa)
Poisson’s ratio (minimum): 0.38
Amine GRE downhole pipe data table 1:
|
Nominal Diameter (in)
|
Field application
|
Pressure rating(Mpa)
|
Inner diameter (mm)
|
Outer diameter (mm)
|
Coupling OD (mm)
|
Weight kg/m
|
Length(m)
|
|
2-1/2"
|
General injection well
|
14
|
56
|
69
|
103
|
2.5
|
8.7
|
|
General injection well
|
16
|
56
|
72
|
103
|
3
|
8.7
|
|
General injection well
|
20
|
56
|
76
|
103
|
3.9
|
8.7
|
|
3"
|
Stratified injection well
|
20
|
62
|
79
|
107
|
4.8
|
8.7
|
|
Eccentric wear pumping well
|
20
|
62
|
79
|
107
|
4.8
|
8.7
|
|
3"
|
Marine tube
|
20
|
62
|
82
|
118
|
4.95
|
8.7
|
Amine GRE downhole pipe data table 2:
|
Nominal Diameter (in)
|
Field application
|
Pressure rating(Mpa)
|
Tensile load grade (kg)
|
Ultimate tensile load (kg)
|
External pressure grade (Mpa)
|
Ultimate external pressure grade (Mpa)
|
|
2-1/2"
|
General injection well
|
14
|
14000
|
20430
|
13.8
|
48.3
|
|
General injection well
|
16
|
16000
|
20430
|
15.5
|
66.2
|
|
General injection well
|
20
|
18000
|
20430
|
17.2
|
88.3
|
|
3"
|
Stratified injection well
|
20
|
15000
|
27240
|
20.7
|
191.1
|
|
Eccentric wear pumping well
|
20
|
15000
|
27240
|
20.7
|
191.1
|
|
3"
|
Marine tube
|
20
|
16000
|
30000
|
20.7
|
191.1
|
Remark: The data may vary with the materials which you choose!
 |
